Tipo di cuscinetto: Due portapalline
Materiale: Impeller &Frame: plastica (UL94V-0)
fili di piombo: UL100735; AWG26
"nbsp; Red Wire Positive (+)
nbsp; Negativo del filo nero一)
Peso: 20.0g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA05010_12L | B/S/F | 12 | 7~13.2 | 0.1 | 4500 | 8.6 | 2.2 | 25 |
| WSA05010_12M | B/S/F | 12 | 7~13.2 | 0.12 | 5500 | 10.5 | 0.14 | 30 |
| WSA05010_12H | B/S/F | 12 | 7~13.2 | 0.14 | 6500 | 12.7 | 0.18 | 35 |
| WSA05010_12U | B/S/F | 12 | 7~13.2 | 0.16 | 7500 | 14.6 | 0.21 | 39 |
| WSA05010_24L | B/S/F | 24 | 12~28 | 0.04 | 4500 | 8.6 | 2.2 | 25 |
| WSA05010_24M | B/S/F | 24 | 12~28 | 0.06 | 5500 | 10.5 | 0.14 | 30 |
| WSA05010_24H | B/S/F | 24 | 12~28 | 0.08 | 6500 | 12.7 | 0.18 | 35 |
| WSA05010_24U | B/S/F | 24 | 12~28 | 0.1 | 7500 | 14.6 | 0.21 | 39 |
